Multi Spindle Thread Verification Units for Integration

A 3-Spindle Thread-Verification Head supplied for an automated subframe application. The tools pass through clearance holes to verify the threads.

This Multi-spindle Head verifies thirty-nine M6 blind holes simultaneously. Compliant toolholders accommodate X-Y and angular positioning errors. Thread depths are individually set with fingerwheels, and a set of thread depth masters were supplied for this job. The parts here are automotive Cam Covers.

A 2-Spindle Gaging Unit for large threads in a defense application.

A Single-Spindle Unit in use for automotive subframes.

An 8-Spindle Thread-Chasing Head cleaning out paint from M12 internal threads.

A four-spindle Station, in use in a plant in India.

This color display shows the status of each threaded hole in a round pattern of eight holes.

This Multi-Spindle Thread-Verification Unit simultaneously “GO” verifies 57 threads in two engine covers.

Features
Videos
Resources
Get a Quote

Available as single-spindle Units, multiple-spindle Heads or complete Stations.
Used to form, verify or remediate threaded holes (or external threads) by engaging appropriate thread tools with various threaded features.
Will simultaneously form, verify or remediate threads of different sizes and pitches.
Spindles are set individually for different torques and thread depths.
Spindle Units can be equipped with compliant toolholders — to accommodate out-of-position holes.
Not subject to damage from broken taps, missing or displaced holes, etc.
Will not jam or stick in undersize or short threads. Won’t crossthread.
Supplied proven out for your application.
